Main Technical Parameters
| Qauv | JH-BM550AP*2 | JH-BM550AP*2 |
| Hnab Ua Dav | 200-400 hli | 200-500 hli |
| Hnab Ua Ntev | 300-650 hli | 300-750 hli |
| Hnab Ua Thickness | 0.005-0.05 hli | 0.005-0.05 hli |
| Hnab Ua Ceev | 200-400pcs / min * 2 | 200-400pcs / min * 2 |
| Cua Siab | 7.5hp ib | 7.5hp ib |
| Tag Nrho Lub Zog | 16 kWm | 18 kWm |
| Qhov hluav taws xob | Ac 380V / 50HZ | Ac 380V / 50HZ |
| Tshuab hnyav | 3000 kg | 3 200kg |
| Qhov Loj (L * W * H) | 7500 x 1700 x 1700 mm | 8500 x 1900 x 1700 mm |
Lub hnab ntim tsis siv neeg puv puv tshuab ua lub tshuab no yog ib qho kev daws teeb meem uas tsim los rau siab -kev ceev ntau lawm thiab ntim khoom ntim ntawm T- lub hnab tsho, hnab tsho khuam, thiab hnab khw. Kev koom ua ke lub hnab ua, suav, folding, thiab ntim tshuab, nws pab cov tuam txhab txhim kho kev tsim khoom thiab txo cov nqi zog.
Lub hnab dav li ntawm 200-500mm, thiab ntev ntawm 300-750mm, haum rau ntau qhov ntau thiab tsawg lub hnab. Lub tshuab txhawb nqa PE zaj duab xis thicknesses los ntawm 0.005-0.05mm thiab ua tiav cov khoom ruaj khov ceev txog li 200-400 hnab ib feeb. Nws siv 16KW-18KW lub cev muaj zog thiab xav tau 7.5HP cua siab kom ntseeg tau tias kev ua haujlwm tsis tu ncua.
Qhov no lub hnab ntim khoom siv lub hnab ntim tshuab tsim lub hom phiaj los pab cov tuam txhab txuag cov nqi thiab yog qhov kev xaiv zoo tshaj plaws rau cov hnab yas loj loj tsim cov nroj tsuag nrhiav kev daws teeb meem automated ntim.
Khoom nta
Dual -kab Unwinding & Tension Control Unit
Kev tswj qhov nro ntawm cov khoom siv membrane thiab kho qhov sib txawv ntawm qhov sib txawv kom ntseeg tau tias cov khoom siv membrane tau noj zoo, ntawm qhov sib txawv ntawm qhov ceev, thiab meej rau hauv qab tom qab sealing thiab txiav chaw nres tsheb.
Hauv qab cua sov- sealing thiab tshav kub- txiav unit
Rau ob - txheej yas zaj duab xis tsis tu ncua ntawm txoj kev A thiab B, lub tshav kub - sealing ntawm lub hnab hauv qab thiab qhov ruaj khov - ntev melting thiab txiav yog ua tiav ib txhij.
Tes- tuav xuas nrig ntaus
Lub tsho khuam-style kov cutout daim duab qhia meej yog stamped ntawm lub hnab qhib, thiab cov khoom siv ntau dhau hauv nruab nrab raug tshem tawm ib txhij.
Tsis siv neeg zaj duab xis sealing thiab ntim
Lub kaw lus cia li qhwv lub hnab ntim khoom kom zoo nkauj tiav raws li cov khoom ntim, ua PE ntim zaj duab xis daim ntawv thov, kawg kub sealing, thiab txiav.
Peb Qhov Kev Pabcuam
Ua ntej- Kev Sib Tham Muag
Peb cov kws tshaj lij kev muag khoom muab kev tshaj lij tshuab kev pom zoo raws li koj cov kev xav tau ntau lawm, cov khoom siv raw, thiab cov khoom tiav tiav.
Customized Solutions
Peb muab cov txheej txheem tshuab customized kom tau raws li qhov sib txawv ntau lawm, cov qauv ua yeeb yaj kiab, thiab daim ntawv thov ntim.
Installation & Kev cob qhia
Cov kws tshaj lij engineers muaj nyob rau txawv teb chaws installation, tshuab commissioning, thiab cov neeg ua haujlwm kev cob qhia kom ntseeg tau tias kev tsim khoom zoo.
Quality Assurance
Txhua lub tshuab ua tiav kev soj ntsuam zoo thiab sim ua haujlwm ua ntej ua zaub mov xa tuaj kom lav qhov kev ua tau zoo thiab kev ua haujlwm ruaj khov.
Kev pab txhawb nqa
Peb pab pawg kws tshaj lij muab kev txhawb nqa online 24/7, kev daws teeb meem hauv thaj chaw deb, thiab cov lus qhia txog kev saib xyuas raws sij hawm kom txo qis sijhawm.
Ib -Xyoo Warranty
Txhua lub tshuab tuaj nrog ib - xyoo lav. Thaum lub sijhawm lav, peb muab cov khoom hloov pauv dawb rau tsis yog - kev puas tsuaj rau tib neeg thiab kev txhawb nqa lub neej.
FAQ
Q: Lub tshuab no tuaj yeem tsim cov hnab yas dab tsi?
A: Lub tshuab no tau tsim tshwj xeeb rau kev tsim txhua yam ntawm lub tsho khuam (T-} tsho) hnab, nrog rau cov khw muag khoom loj, cov hnab ntim khoom noj, cov hnab ntim khoom tshiab thiab cov hnab ntim khoom tshaj tawm. Nws tseem tuaj yeem tsim cov hnab tiaj tus thaum lub tes xuas nrig ntaus yog muab tua.
Q: Dab tsi yog qhov txawv ntawm JH-BM450AP2 thiab JH-BM550AP2?
A: Qhov sib txawv tseem ceeb yog kev ua haujlwm ntau, lub zog thiab tag nrho qhov loj:
- JH-BM450AP*2: 200-400mm lub hnab dav, 300-650mm lub hnab ntev, 16KW tag nrho lub zog, 3000kg hnyav, 7500 × 1700 × 1700mm dimension
- JH-BM550AP*2: 200-500mm lub hnab dav, 300-750mm lub hnab ntev, 18KW tag nrho lub zog, 3200kg hnyav, 8500 × 1900 × 1700mm dimension Ob leeg yog cov qauv dual-kab nrog tib qhov ceev thiab zaj duab xis thickness compatibility.
Q: Lub peev xwm ntau lawm ntawm lub hnab ua tshuab no yog dab tsi?
A: Nov yog dual - kab siab - qauv nrawm. Txhua kab khiav ntawm qhov ceev ruaj khov ntawm 200-400 daim ib feeb, uas yuav luag ob npaug ntawm cov khoom siv ib zaug - kab tshuab, ua rau nws zoo tagnrho rau cov khoom loj loj.
Q: Cov khoom siv raw li cas nrog lub tshuab no?
A: Nws ua haujlwm nrog HDPE, LDPE thiab LLDPE yas zaj duab xis, nrog rau cov ntaub ntawv biodegradable xws li PLA thiab PBAT. Cov yeeb yaj kiab siv tau yog li ntawm 0.005mm txog 0.05mm.
Q: Lub tshuab no muaj lub luag haujlwm tseem ceeb dab tsi?
A: Lub tshuab yog nruab nrog tag nrho cov txheej txheem ntawm kev teeb tsa: servo lub cev muaj zog tswj rau lub tshuab tseem ceeb, kev ywj pheej nruj- tswj kev noj zaub mov, lub tshuab tsis siv neeg tuav xuas nrig ntaus, tsis siv neeg folding & stacking unit, thiab lub hnab ntim tsis siv neeg tiav. Nws realizes tag nrho tsis siv neeg ntau lawm los ntawm raw zaj duab xis yob rau packed zaum kawg cov khoom.
Q: Dab tsi yog lub zog thiab cua siab xav tau?
A: Lub tshuab siv tus qauv AC380V / 50HZ fais fab mov thiab xav tau 7.5HP cua siab. Lub zog tag nrho yog 16KW rau JH-BM450AP2 qauv thiab 18KW rau JH-BM550AP2 qauv.
Q: Lub tshuab no puas tuaj yeem tsim cov khoom siv biodegradable eco-cov hnab phooj ywg?
A: Yog. Lub tshuab tswj qhov kub thiab txias- qauv sealing yog optimized rau biodegradable zaj duab xis ua, thiab tau tag nrho nrog PLA, PBAT thiab lwm yam khoom siv biodegradable kom tau raws li qhov kev thov ntawm eco- cov phooj ywg ntim.
Q: Lub tshuab no xav tau qhov chaw ua haujlwm ntau npaum li cas?
A: Lub cev tseem ceeb ntawm JH-BM450AP2 ntsuas 7500 × 1700 × 1700mm, thiab JH-BM550AP2 ntsuas 8500 × 1900 × 1700mm. Nws raug nquahu kom khaws qhov chaw ntxiv rau ntawm qhov chaw rau kev tso cov khoom siv raw, cov khoom tiav cia thiab ua haujlwm tu txhua hnub.
Q: Dab tsi tom qab -muag kev pab cuam thiab warranty txoj cai koj muab?
A: Tag nrho cov tshuab tuaj nrog 1-xyoo tag nrho- tshuab warranty, thiab hloov pauv dawb ntawm cov khoom tsis yog- khoom cuav thaum lub sijhawm lav. Peb kuj muab cov kev taw qhia kev teeb tsa txawv teb chaws, kev cob qhia tus neeg teb xov tooj, 24/7 online technical support thiab lub neej tom qab muag kev pabcuam.
Q: Koj puas txhawb kev tsim kho tshuab?
A: Yog. Peb tuaj yeem muab cov kev daws teeb meem raws li koj cov kev xav tau ntau lawm, xws li kev hloov pauv lub hnab tshwj xeeb, hloov hluav taws xob, thiab kev teeb tsa ntxiv. Peb cov kws tsim khoom muag yuav muab cov lus pom zoo raws li koj qhov kev xav tau tshwj xeeb.
